Bioinformatic Analysis of Potential Key
Genes in Castration-resistant Prostate Cancer Development

doi:10.12114/j.issn.1007-9572.2022.02.010

Abstract

Abstract: Background

Castration-resistant prostate cancer (CRPC) is one of the most prevalent cancers in males with a high fatality rate. Its molecular mechanism is still unclear, and there is no effective treatment.

Objective

To explore the key genes involved in CRPC development using bioinformatic analysis, offering new ideas for the diagnosis and treatment of CRPC.

Methods

The data set GSE32269 which contains human primary prostate cancer and CRPC was downloaded from the Gene Expression Omnibus database for further bioinformatic analysis. R language was used to identify differentially expressed genes (DEGs) in CRPC. Gene Ontology (GO) enrichment analysis and Kyoto Encyclopedia of Genes and Genomes (KEGG) pathway analysis of DEGs were further performed by using DAVID. A protein-protein interaction (PPI) network of DEGs was constructed by using STRING database for screening potential key genes. And the identified potential key genes were further analyzed by survival analysis and receiver operating characteristic (ROC) curve analysis.

Results

279 DEGs were identified in microarray dataset GSE32269. GO enrichment analysis and KEGG pathway analysis revealed that cell division, mitosis and cell cycle signaling pathways may play an important role in the development of CRPC. PPI network screening revealed that there were 15 potential key genes, among which CDC20, MAD2L1 and NUSAP1 expressed differentially in CRPC patients: those with highly expressed CDC20, MAD2L1 and NUSAP1 had statistically lower overall survival rate and disease-free survival rate than did those with low expressed CDC20, MAD2L1 and NUSAP1 (P<0.05) . The area under the ROC curve of CDC20, MAD2L1 and NUSAP1 to predict the occurrence of CRPC were 0.933, 0.762, and 0.950, respectively, indicating that each of them may have a high diagnostic value for CRPC.

Conclusion

CDC20, MAD2L1 and NUSAP1 may be key candidate genes associated with the development of CRPC.

Key words: Prostatic neoplasms, Castration-resistant prostate cancer, Key genes, Bioinformatics

摘要： 背景

去势抵抗性前列腺癌（CRPC）是男性常见恶性肿瘤疾病之一，病死率高，分子机制仍不十分清楚，且无有效治疗药物。

目的

应用生物信息学方法挖掘CRPC发生、发展的关键基因，为其诊治提供新思路。

方法

从基因表达综合数据库（GEO）中下载关于人类原发性前列腺癌（PCa）和CRPC的数据集GSE32269并进行生物信息学分析。使用R语言鉴定CRPC的差异表达基因（DEGs）。通过DAVID软件对DEGs进行基因本体论（GO）富集分析及京都基因和基因组百科全书（KEGG）通路分析。利用STRING在线数据库构建蛋白质-蛋白质相互作用（PPI）网络进一步筛选关键基因，并对关键基因进行生存分析和受试者工作特征（ROC）曲线分析。

结果

通过对微阵列数据集GSE32269分析共筛选出279个DEGs，进一步通过GO富集分析和KEGG通路分析发现在CRPC发展中，细胞分裂、有丝分裂和细胞周期等信号通路发挥重要作用。PPI网络分析筛选出15个关键基因，对关键基因进行生存分析发现：CDC20、MAD2L1和NUSAP1高表达组CRPC患者总生存率和无病生存率均分别低于CDC20、MAD2L1和NUSAP1低表达组（P<0.05）；且CDC20、MAD2L1和NUSAP1预测CPRC发生的ROC曲线下面积分别为0.933、0.762、0.950，提示其对CRPC具有较高的诊断价值。

结论

CDC20、MAD2L1和NUSAP1可能是参与CRPC发展的关键候选基因。

关键词: 前列腺癌, 去势抵抗性前列腺癌, 关键基因, 生物信息学

CLC Number:

R737.25

DONG Jingting, HENG Li, KANG Shaosan, LIU Jian, TIAN Zhichong, ZHANG Liguo, ZHANG Jincun, LI Zhiguo, SHEN Hong, CAO Fenghong.

Bioinformatic Analysis of Potential Key Genes in Castration-resistant Prostate Cancer Development [J]. Chinese General Practice, 2022, 25(08): 937-944.

董婧婷,衡立,康绍叁等. 去势抵抗性前列腺癌潜在关键基因的生物信息学分析[J]. 中国全科医学, 2022, 25(08): 937-944. DOI: 10.12114/j.issn.1007-9572.2022.02.010.

Figures/Tables 11

References 49

[1]	CHUNG B H, HORIE S, CHIONG E. Clinical studies investigating the use of leuprorelin for prostate cancer in Asia[J]. Prostate Int，2020，8(1):1-9. DOI：10.1016/j.prnil.2019.06.001.
[2]	SANTER F R, ERB H H H, MCNEILL R V. Therapy escape mechanisms in the malignant prostate[J]. Semin Cancer Biol，2015，35:133-144. DOI：10.1016/j.semcancer.2015.08.005.
[3]	KIRBY M, HIRST C, CRAWFORD E D. Characterising the castration-resistant prostate cancer population：a systematic review[J]. Int J Clin Pract，2011，65(11):1180-1192. DOI：10.1111/j.1742-1241.2011.02799.x.
[4]	HARRIS W P, MOSTAGHEL E A, NELSON P S，et al. Androgen deprivation therapy：progress in understanding mechanisms of resistance and optimizing androgen depletion[J]. Nat Clin Pract Urol，2009，6(2):76-85. DOI：10.1038/ncpuro1296.
[5]	PUNIT S, DRABOVICH A P, JARVI K A，et al. Mechanisms of androgen-independent prostate cancer[J]. EJIFCC，2014，25(1):42-54.
[6]	GUO J S, GU Y Z, MA X Y，et al. Identification of hub genes and pathways in adrenocortical carcinoma by integrated bioinformatic analysis[J]. J Cell Mol Med，2020，24(8):4428-4438. DOI：10.1111/jcmm.15102.
[7]	SUN Z L, MAO Y H, ZHANG X，et al. Identification of ARHGEF38，NETO2，GOLM1，and SAPCD2 associated with prostate cancer progression by bioinformatic analysis and experimental validation[J]. Front Cell Dev Biol，2021，9:718638. DOI：10.3389/fcell.2021.718638.
[8]	SHEN H, GUO Y L, LI G H，et al. Gene expression analysis reveals key genes and signalings associated with the prognosis of prostate cancer[J]. Comput Math Methods Med，2021，2021:9946015. DOI：10.1155/2021/9946015.
[9]	GU P, YANG D R, ZHU J，et al. Bioinformatics analysis identified hub genes in prostate cancer tumorigenesis and metastasis[J]. Math Biosci Eng，2021，18(4):3180-3196. DOI：10.3934/mbe.2021158.
[10]	PARRISH R S, SPENCER H J 3rd. Effect of normalization on significance testing for oligonucleotide microarrays[J]. J Biopharm Stat，2004，14(3):575-589. DOI：10.1081/BIP-200025650.
[11]	FERREIRA J A. The Benjamini-Hochberg method in the case of discrete test statistics[J]. Int J Biostat，2007，3(1):Article11. DOI：10.2202/1557-4679.1065.
[12]	HUANG D W, SHERMAN B T, LEMPICKI R A. Bioinformatics enrichment tools：paths toward the comprehensive functional analysis of large gene lists[J]. Nucleic Acids Res，2009，37(1):1-13. DOI：10.1093/nar/gkn923.
[13]	ASHBURNER M, BALL C A, BLAKE J A，et al. Gene ontology：tool for the unification of biology. The Gene Ontology Consortium[J]. Nat Genet，2000，25(1):25-29. DOI：10.1038/75556.
[14]	OGATA H, GOTO S, SATO K，et al. KEGG：Kyoto encyclopedia of genes and genomes[J]. Nucleic Acids Res，1999，27(1):29-34. DOI：10.1093/nar/27.1.29.
[15]	WALTER W, SÁNCHEZ-CABO F, RICOTE M. GOplot：an R package for visually combining expression data with functional analysis[J]. Bioinformatics，2015，31(17):2912-2914. DOI：10.1093/bioinformatics/btv300.
[16]	SNEL B, LEHMANN G, BORK P，et al. STRING：a web-server to retrieve and display the repeatedly occurring neighbourhood of a gene[J]. Nucleic Acids Res，2000，28(18):3442-3444. DOI：10.1093/nar/28.18.3442.
[17]	SAITO R, SMOOT M E, ONO K，et al. A travel guide to Cytoscape plugins[J]. Nat Methods，2012，9(11):1069-1076. DOI：10.1038/nmeth.2212.
[18]	BADER G D, HOGUE C W V. An automated method for finding molecular complexes in large protein interaction networks[J]. BMC Bioinformatics，2003，4:2. DOI：10.1186/1471-2105-4-2.
[19]	GUO Y Z, SUN H H, WANG X T，et al. Transcriptomic analysis reveals key lncRNAs associated with ribosomal biogenesis and epidermis differentiation in head and neck squamous cell carcinoma[J]. J Zhejiang Univ Sci B，2018，19(9):674-688. DOI：10.1631/jzus.B1700319.
[20]	TANG Z F, LI C W, KANG B X，et al. GEPIA：a web server for cancer and normal gene expression profiling and interactive analyses[J]. Nucleic Acids Res，2017，45(W1):W98-102. DOI：10.1093/nar/gkx247.
[21]	ROBIN X, TURCK N, HAINARD A，et al. pROC：an open-source package for R and S+ to analyze and compare ROC curves[J]. BMC Bioinformatics，2011，12:77. DOI：10.1186/1471-2105-12-77.
[22]	YAO F, ZHU Z F, WEN J，et al. PODN is a prognostic biomarker and correlated with immune infiltrates in osteosarcoma[J]. Cancer Cell Int，2021，21(1):381. DOI：10.1186/s12935-021-02086-5.
[23]	CHANDRASEKAR T, YANG J C, GAO A C，et al. Mechanisms of resistance in castration-resistant prostate cancer （CRPC）[J]. Transl Androl Urol，2015，4(3):365-380. DOI：10.3978/j.issn.2223-4683.2015.05.02.
[24]	MARCUS A I, PETERS U, THOMAS S L，et al. Mitotic kinesin inhibitors induce mitotic arrest and cell death in Taxol-resistant and-sensitive cancer cells[J]. J Biol Chem，2005，280(12):11569-11577. DOI：10.1074/jbc.M413471200.
[25]	HE H Q, HAO J, DONG X，et al. ZRSR2 overexpression is a frequent and early event in castration-resistant prostate cancer development[J]. Prostate Cancer Prostatic Dis，2021，24(3):775-785. DOI：10.1038/s41391-021-00322-7.
[26]	WANG Q, LI Z A, YANG J，et al. Loss of NEIL3 activates radiotherapy resistance in the progression of prostate cancer[J]. Cancer Biol Med，2021. DOI：10.20892/j.issn.2095-3941.2020.0550.
[27]	KIM M Y, JUNG A R, SHIN D，et al. Niclosamide exerts anticancer effects through inhibition of the FOXM1-mediated DNA damage response in prostate cancer[J]. Am J Cancer Res，2021，11(6):2944-2959.
[28]	YU H T. Cdc20：a WD40 activator for a cell cycle degradation machine[J]. Mol Cell，2007，27(1):3-16. DOI：10.1016/j.molcel.2007.06.009.
[29]	GAYYED M F, EL-MAQSOUD N M, TAWFIEK E R，et al. A comprehensive analysis of CDC20 overexpression in common malignant tumors from multiple organs：its correlation with tumor grade and stage[J]. Tumour Biol，2016，37(1):749-762. DOI：10.1007/s13277-015-3808-1.
[30]	WANG L X, YANG C L, CHU M，et al. Cdc20 induces the radioresistance of bladder cancer cells by targeting FoxO1 degradation[J]. Cancer Lett，2021，500:172-181. DOI：10.1016/j.canlet.2020.11.052.
[31]	YANG G, WANG G, XIONG Y F，et al. CDC20 promotes the progression of hepatocellular carcinoma by regulating epithelial-mesenchymal transition[J]. Mol Med Rep，2021，24(1):483. DOI：10.3892/mmr.2021.12122.
[32]	DAI L, SONG Z X, WEI D P，et al. CDC20 and PTTG1 are important biomarkers and potential therapeutic targets for metastatic prostate cancer[J]. Adv Ther，2021，38(6):2973-2989. DOI：10.1007/s12325-021-01729-3.
[33]	ZHANG Q, HUANG H, LIU A，et al. Cell division cycle 20 （CDC20） drives prostate cancer progression via stabilization of β-catenin in cancer stem-like cells[J]. EBioMedicine，2019，42:397-407. DOI：10.1016/j.ebiom.2019.03.032.
[34]	LI K, MAO Y H, LU L，et al. Silencing of CDC20 suppresses metastatic castration-resistant prostate cancer growth and enhances chemosensitivity to docetaxel[J]. Int J Oncol，2016，49(4):1679-1685. DOI：10.3892/ijo.2016.3671.
[35]	TO-HO K W, CHEUNG H W, LING M T，et al. MAD2DeltaC induces aneuploidy and promotes anchorage-independent growth in human prostate epithelial cells[J]. Oncogene，2008，27(3):347-357. DOI：10.1038/sj.onc.1210633.
[36]	WU Y, TAN L M, CHEN J J，et al. MAD2 combined with mitotic spindle apparatus （MSA） and anticentromere antibody （ACA） for diagnosis of small cell lung cancer （SCLC）[J]. Med Sci Monit，2018，24:7541-7547. DOI：10.12659/MSM.909772.
[37]	LI Y H, BAI W J, ZHANG J J. miR-200c-5p suppresses proliferation and metastasis of human hepatocellular carcinoma （HCC） via suppressing MAD2L1[J]. Biomed Pharmacother，2017，92:1038-1044. DOI：10.1016/j.biopha.2017.05.092.
[38]	CHOI J W, KIM Y, LEE J H，et al. High expression of spindle assembly checkpoint proteins CDC20 and MAD2 is associated with poor prognosis in urothelial bladder cancer[J]. Virchows Arch，2013，463(5):681-687. DOI：10.1007/s00428-013-1473-6.
[39]	RAEMAEKERS T, RIBBECK K, BEAUDOUIN J，et al. NuSAP，a novel microtubule-associated protein involved in mitotic spindle organization[J]. J Cell Biol，2003，162(6):1017-1029. DOI：10.1083/jcb.200302129.
[40]	GORDON C A, GONG X, GANESH D，et al. NUSAP1 promotes invasion and metastasis of prostate cancer[J]. Oncotarget，2017，8(18):29935-29950. DOI：10.18632/oncotarget.15604.
[41]	GULZAR Z G, MCKENNEY J K, BROOKS J D. Increased expression of NuSAP in recurrent prostate cancer is mediated by E2F1[J]. Oncogene，2013，32(1):70-77. DOI：10.1038/onc.2012.27.
[42]	GORDON C A, GULZAR Z G, BROOKS J D. NUSAP1 expression is upregulated by loss of RB1 in prostate cancer cells[J]. Prostate，2015，75(5):517-526. DOI：10.1002/pros.22938.
[43]	WU Y G, LIU H X, GONG Y F，et al. ANKRD22 enhances breast cancer cell malignancy by activating the Wnt/β-catenin pathway via modulating NuSAP1 expression[J]. Bosn J Basic Med Sci，2021，21(3):294-304. DOI：10.17305/bjbms.2020.4701.
[44]	GUO H, ZOU J P, ZHOU L，et al. NUSAP1 promotes gastric cancer tumorigenesis and progression by stabilizing the YAP1 protein[J]. Front Oncol，2020，10:591698. DOI：10.3389/fonc.2020.591698.
[45]	ZHANG Y Y, HUANG K T, CAI H H，et al. The role of nucleolar spindle-associated protein 1 in human ovarian cancer[J]. J Cell Biochem，2020，121(11):4397-4405. DOI：10.1002/jcb.29661.
[46]	XU Z Y, WANG Y, XIONG J，et al. NUSAP1 knockdown inhibits cell growth and metastasis of non-small-cell lung cancer through regulating BTG2/PI3K/Akt signaling[J]. J Cell Physiol，2020，235(4):3886-3893. DOI：10.1002/jcp.29282.
[47]	GAO S, YIN H B, TONG H，et al. Nucleolar and spindle associated protein 1 （NUSAP1） promotes bladder cancer progression through the TGF-β signaling pathway[J]. Onco Targets Ther，2020，13:813-825. DOI：10.2147/OTT.S237127.
[48]	LI H, ZHANG W J, YAN M，et al. Nucleolar and spindle associated protein 1 promotes metastasis of cervical carcinoma cells by activating Wnt/β-catenin signaling[J]. J Exp Clin Cancer Res，2019，38(1):33. DOI：10.1186/s13046-019-1037-y.
[49]	LIU Z X, GUAN C Q, LU C H，et al. High NUSAP1 expression predicts poor prognosis in colon cancer[J]. Pathol Res Pract，2018，214(7):968-973. DOI：10.1016/j.prp.2018.05.017.

ID	描述
GO:0030198	细胞外基质组织
GO:0007155	细胞黏附
GO:0051301	细胞分裂
GO:0030199	胶原纤维组织
GO:0030574	胶原蛋白分解代谢过程
GO:0000070	有丝分裂姐妹染色单体分离
GO:0006909	吞噬作用
GO:0007067	有丝分裂核分裂
GO:0051988	调节纺锤体微管与着丝点附着
GO:0000281	有丝分裂胞质分裂

ID	描述
GO:0030198	细胞外基质组织
GO:0007155	细胞黏附
GO:0051301	细胞分裂
GO:0030199	胶原纤维组织
GO:0030574	胶原蛋白分解代谢过程
GO:0000070	有丝分裂姐妹染色单体分离
GO:0006909	吞噬作用
GO:0007067	有丝分裂核分裂
GO:0051988	调节纺锤体微管与着丝点附着
GO:0000281	有丝分裂胞质分裂

ID	描述
GO:0070062	细胞外外泌体
GO:0031012	细胞外基质
GO:0005578	蛋白质细胞外基质
GO:0005615	细胞外空隙
GO:0030496	中间体
GO:0005788	内质网腔
GO:0005581	胶原蛋白三聚物
GO:0005737	细胞质
GO:0051233	中央区
GO:0005604	基底膜

ID	描述
GO:0070062	细胞外外泌体
GO:0031012	细胞外基质
GO:0005578	蛋白质细胞外基质
GO:0005615	细胞外空隙
GO:0030496	中间体
GO:0005788	内质网腔
GO:0005581	胶原蛋白三聚物
GO:0005737	细胞质
GO:0051233	中央区
GO:0005604	基底膜

ID	描述
GO:0005201	细胞外基质结构成分
GO:0005515	蛋白质结合
GO:0005518	胶原蛋白质结合
GO:0050840	细胞外基质结合
GO:0005178	整合素结合
GO:0008307	肌肉结构成分
GO:0048407	血小板衍生生长因子结合
GO:0019901	蛋白激酶结合
GO:0008201	肝素结合
GO:0051015	肌动蛋白丝结合
